• Power Spring PS-037

Power Spring PS-037

Model : PS-037


  • Material : Type 301 stainless steel is typically used for most applications. High-carbon steel and other materials may be required.
  • A wide variety of materials are available for use depending on your application.
  • Thickness : 0.04 - 1.0mm
  • Width : 2.5 - 90mm


Introduction

[Power Spring] / [Customized Power Spring]

Power springs are made of rectangular section material, Power springs are wound flat, and have either special retaining holes or bends on both ends.  As the length-to-thickness ratio (L/t) increases, the spiral space between coils increases rapidly.  To reduce the space required and maintain a reasonable amount of deflection (turns), power springs are retained in some type of housing or case in application.

Feature of Spring

[Power Spring]


power springs


1. Material

2. T=Material thickness

3. W=Width

4. Da=Shaft diameter(recommended)

5. R=inside diameter of holder

6. N=Number of coils


Application
[Power Spring]

Power spring are mainly used in clock, spring motors for toys. timers, as well as in retractor mechanisms for electrical cords, compressor pipes and seat belts.

Power Diagram
[Power Spring]


power springs
