Motor Brush TS-002

  • Motor Brush TS-002

Model : TS-002

Q'ty :

Add To Inquiry


  • Material : Type 301 stainless steel is typically used for most applications. High-carbon steel and other materials may be required.
  • A wide variety of materials are available for use depending on your application.
  • Thickness : 0.04 - 1.0mm
  • Width : 2.5 - 90mm


Introduction

[Spring For Motor Brush Sigle coil/Twin coil ] / [Customized Spring For Motor Brush Sigle Coil/Twin Spring]

Application for Constant Force spring for carbon brush, the characteristic not only decrease noise and reduces spark also lower influence of electromagnetic interference (EMI). Certainly be able to keep constant pressure for commutator no matter brush length. Constant Force spring indeed can be design or produce base on what's your demands to meet all customization. On the other words of cost saving, reduce replacement and larger commutators come to promote the functions of motor as well in addition to adjust the brush length for products value in order to extend and strengthening market with competitive superiority.

Feature of Spring
[Motor Brush/Twin Spring]



1. Material

2. T=Material thickness

3. W=Width

4. Total length

5. O.D.=Outside diameter

6. In/Ext=Initial extension

7. A=End configuration centerline hole to end

8. B=End configuration hole diameter

9. Load


-------------------------------------------------------------------------------------------------------------------------------------



1. Material

2. Thickness

3. A=Width of carbon brush

4. O.D=Outside diameter

5. Wo/Ext=working Extension

6. Load


Application
[Motor Brush/Twin Spring]
